Raven Rate Controller

Provides great reliability and versatility, making time in the field easier.

Hydraulic Valve Block

Bosch Rexroth hydraulic valve block controls spinners, decreasing fluctuation, improving consistency, and giving greater flexibility.

Rear Spinner Frame

New rear spinner frame with under-disc spinners allows easier service and maintenance. Open design ensures even flow and greatly reduces bridging.

Electric Rear Door

Actuator automatically sets rear door height and sends position back to the rate controller, ensuring consistent and accurate application rates.

Side and End Walls

One-piece side walls and 6 mm end walls provide robust, durable construction built to endure the harshest environments.

Hydraulic Roller Drive

Rubber-lagged drive pulley on a 55 mm shaft increases longevity for belt and roller.

Self-Cleaning Tail Pulley

Rubber-lagged pulley prevents material build-up. Delivery auger tube constructed from ERW 10 mm line pipe.

Cross Auger System

Solid, robust, longer-wearing cross auger in drop box creates a consistent unload rate.

Folding Auger Linkage

3‑point hitch with variable speed allows smooth folding of the auger with no bounce.

Auger Flighting

Grain pick-up and drop-off points have 6 mm auger flighting segments for greater efficiency and durability.

Spinner Speed Control

Independent spinner control with live speed feedback from both spinners, controlled individually via PWM, providing accurate speed control and ease of troubleshooting.

Wide Cleated Belt

1‑metre-wide cleated belt with polyurethane skirts, the widest in the industry, allowing smooth, even material flow and enabling high-rate bulk application.

Roll-Over Tarp

Heavy-duty tarp, easily accessible for quick product protection.

Hydraulic Steering Option

Provides greater manoeuvrability around silos and on headlands.

PTO Drive System

100 hp Bondioli & Pavesi PTO with inbuilt clutch for smooth, reliable engagement and unloading with override clutch.

Curved Back Spinner

Curved back spinner with bevel edge spinner discs for controlled distribution.

Variable Sized Cones

Adjustable cones spread all products quickly and easily.

Sliding Axle System

Axle slides from 2 m to 3 m wheel centres, providing greater versatility for all farming practices.

Modern Design

Stylish, integrated structure; Australian owned and manufactured.

Curved Side Panels

Curved sides add extra strength and aesthetic appeal with an innovative, long-lasting design. Different size tow-bar bush suits all drawbar pin sizes.

Machine Capacity

26,000 ltr Capacity at water level
Lime 32.5T
Urea 19.7T
40,000 ltr Capacity at water level
Wheat 32T
Urea 30T
Dual Axle Machine
520/85 R38 Floatation Tyres
Front and Rear rollers Hydraulically driven

Machine Dimensions

Machine tare weight with Delivery auger and hungry boards - 12T
Drawbar Load - 3T
Hopper Length - 8.13 m
Overall Length -
Overall Width - 3.49 m
Overall Height - 3.74 m

Machine Specifications

Volume (Without Hungry Boards) - 26,000L
Volume (With Hungry Boards) - 40,000L
Tare Weight - 11.8T
Max. Load - 34T
Gross Weight - 45.8T
Drawbar Load (Loaded) - 3.8T
Load Per Tyre (Loaded) - 10.5T

Delivery Auger with Hungry Boards

Raven RCM Rate Controller

Weight Scales Interfaced with Raven

Agrimatics added to Raven Weight Scales

Steerable Axle

Camera Pack

Light Pack

Brakes Front Axle

Side Delivery Chute

Front Tyre Protectors

800 mm Auger Extension

9 ltr Fire Extinguisher

4 Metre Wheel Centres
